Model |
FD10-250c |
FD10-320c |
FD10-400c |
|
Min. internal diameter (mm) |
Φ250 |
Φ320 |
Φ400 |
|
Length of workpiece (mm) |
≤2000 |
≤3000 |
≤4000 |
|
Movement stroke of slide (V×H) / mm |
25×25 |
30×60 |
50×100 |
|
Wire diameter (mm) |
Φ1.2～Φ1.6 |
Φ2.4～Φ3.0 |
Φ3.0～Φ4.0 |
|
Wire strengthen accuracy (mm) |
≤±1 (Extend 20 mm) |
≤±1 (Extend 30 mm) |
≤±1 (Extend 40 mm) |
|
Seam type |
Longitudinal |
Longitudinal circumferential |
Longitudinal circumferential |
|
Rated welding current (A) |
630 |
1000 |
1000 |
|
Duty cycle |
100% |
||
